MULTIFUNCTION ELECTRIC BRAISER

Model SE7BR4/FIX

Code 07825000

Internal and external construction entirely in stainless steel, external surfaces with scotch brite finish.

Cooking tub with bottom and sides in AISI 304 stainless steel, 20/10 thick; radiant tub bottom in

COMPOUND steel, 15 mm thick, mirror polished.

The two-component cooking surface combines a layer of steel, to provide more uniform cooking, and a top coating in AISI 316 stainless steel with a polished finish, which allows excellent cleaning, low radiation levels making the operator’s work more comfortable.

50 mm diameter discharge hole and duct in to the steel GN 1/1 tray.

Manual reset safety thermostat.

Uniform heating to the bottom given by heating elements armoured in Incoloy-800, fixed to the bottom of the tub and coated with insulating material.

Power supply controlled by a switch and thermostat ( 100°C - 300°C).

Show more Hide

Technical specifications

Tank

L of capacity

11,5

Details

total electric kW	4.8
Electrical voltage	380-415 V3N

Measurements

Width	400
Depth	730
Height	900
Weight	60
Volume	0.26

Package

Package width	480
Package depth	800
Package height	1210
Package weight	71
Package volume	0.46
